Name: M5 Ultra Music Player DAP
SKU: 233067

Product Details ＋

The Shanling M5 Ultra DAP Music Player is the epitome of cutting-edge audio technology and sophisticated design. At its core, the M5 Ultra is powered by the flagship AKM DAC AK4499EX and the AK4191 modulator, ensuring unmatched sound clarity and precision. The new body design features an illuminated wheel, adding a touch of elegance and ease of control.

The M5 Ultra supports high-resolution audio up to 32bit/768kHz and DSD512 natively, offering an immersive listening experience. The MTouch system provides an intuitive user interface, while the Ingenic X2000 platform and 3rd generation FPGA guarantee seamless performance. With KDS active crystal oscillators, the device ensures precise timing for superior audio reproduction.

Stay connected with Bluetooth 5.2 bi-directional system and WiFi support for DLNA and Airplay, making streaming effortless. Enjoy up to 11 hours of continuous playback and an impressive 528 hours on standby. Tailor your listening experience with three levels of gain and six digital filters, making the Shanling M5 Ultra the ultimate music player for audiophiles.

Dragon Cable Recommendation: We recommend pairing the Shanling M5 Ultra DAP Music Player with our popular . The Black Dragon USB cable utilizes our single crystal UP-OCC copper construction to provide you with the best possible digital bus transmission. Our Black Dragon USB cable will bring an extraordinary amount of detail and resolution to your hi-fi system. The Black Dragon USB cable is designed to transfer digital audio from your source device (like a computer, phone, tablet, or digital audio player) to a USB-capable DAC. It is built to USB Audio specs. The Black Dragon USB Cable is meant for audio data transfer only - meaning that this cable should not be used for high-speed data transmission (via external hard drives). Because of the high-quality materials and cable geometry, Dragon USB cables greatly reduce stock USB cable issues such as packet loss and jitter.

Features:

Flagship AKM DAC AK4191 Modulator
New Body Design
Illuminated Wheel
32bit/768kHz, DSD512 Native
MTouch System
Bluetooth 5.2 Bi-Directional System
Ingenic X2000 Platform
3rd Generation FPGA
KDS Active Crystal Oscillators
WiFi Support for DLNA, Airplay
Up to 11 Hours of Playback, 528 hours on Standby
Three Levels of Gain
Six Digital Filters

Shanling M5 Ultra is the first player to reveal Shanling's new body design, abandoning smooth round lines for more aggressive angular shapes and edges. Its construction follows Shanling's high standards, with a machined aluminum frame and glass panels, a bright 4.7-inch HD touchscreen, a trio of hardware buttons for playback control, and Shanling's classic volume wheel, now with extra illumination.

Running on the Ingenic X2000 platform, featuring Shanling's latest generation of the MTouch system, the M5 Ultra offers a customizable main menu for quick access to all files stored on a MicroSD card. It also includes the built-in Tidal Online Streaming app (to be added with a firmware update) and offers a wide range of other playback modes, including USB DAC, DLNA, Airplay, and Bluetooth Receiver. The M5 Ultra is now updated with a new wireless module for Bluetooth 5.2 support.

The audio section of the M5 Ultra combines Shanling's experience with the H7 and M9 Plus. It inherits the balanced amplifier built around Texas Instruments TPA6120A2 and the flagship AKM AK4499EX DAC and AK4191 modulator from the H7 while incorporating the improved I/V conversion stage from the M9 Plus. This results in Shanling's favorite smooth and slightly warm sound, with deep-reaching sub-bass, a rich soundstage, and plentiful detail. With its powerful amplifier, providing up to 1100 mW @ 32 Ohm, the M5 Ultra stands as one of Shanling's most powerful portable players, right alongside the flagship M9 Plus.

New Body Design - Modern & Sharp Light Bending Angles

In a significant deviation from classic Shanling design, the M5 Ultra embraces a modern style featuring irregular shapes and pronounced edges, with aluminum construction available in black or silver finishes. Utilizing the latest generation of Shanling's in-house MTouch OS, it offers a simple and fast system focused on pure audio playback, refined through over six years of development and improvements.

4.7-inch HD Touch Screen
Aluminum Construction
In-House MTouch OS

AKM AK4499EX AK4191 Modulator DACs

Adopting the same I/V conversion design as Shanling's flagship portable player, the M5 Ultra features the best AKM DAC, expertly tuned by Shanling's experienced engineers, reflecting 36 years of Hi-Fi history. It delivers the best of the traditional Shanling sound in a portable package.

Flagship Japanese Chipset - Warm, Smooth, Dynamic, and Flowing.

Advanced High Fidelity Audio Design

The M5 Ultra features the best of Shanling audio design, from the TPA6120A2-based amplifier to the advanced FPGA and XMOS USB input. Incorporating many components from the popular H5 and H7 models, it approaches sound in a unique way compared to standard Android portable players.

Texas Instruments TPA6120A2 Amplifier
USB Input XMOS XU316
High-Precision Resistors
Low-Pass Filter OPA2211 Op-Amp
3rd Generation FPGA & KDS Active Crystal Oscillators
AD4523 Inspired by High End Adapted from the M9 Plus
Panasonic Tantalum Capacitors
ELNA Silmic II Capacitors

Versatile Amplifier with Enhanced Power Output

With up to 1100mW at 32ohms on the balanced output, it matches Shanling's most powerful high-end portable player at a notably lower price. Featuring three gain stage settings, it effortlessly transitions from demanding full-size headphones to the most sensitive earphones, showcasing its versatility.

Plus-Sized Battery for High Power Demands

To complement its power-hungry audio components, the M5 Ultra boasts a larger 6000 mAh battery, controlled by a proprietary PMU chip. Providing up to 11 hours of continuous playback and supporting fast 15W charging.

11 hours single-ended
9 hours balanced
32.5 hours Bluetooth
528 hours on standby

Upgraded Bluetooth 5.2 - Ideal for 2-Way Connections

Features 2-way support for LDAC, ampX HD, aptX, AAC, and SBC. The new wireless module in the M5 Ultra offers enhanced 2-way Bluetooth capabilities. This allows seamless connection to Bluetooth headphones or speakers while also functioning as a high-fidelity Bluetooth DAC/Amp.

Synclink with the Eddict Player Companion App

Connect to the Eddict Player app on Android or iOS for remote control of playback on the M5 Ultra. Enjoy the convenience of browsing through the MicroSD card memory seamlessly.

Wi-Fi Connectivity: Stream with DLNA and Airplay

Connect M5 Ultra to your local network, and it will appear as another endpoint for your home streaming network. Perfect for versatile roles, connecting to larger audio setups.
