Product Details
＋
| Video/Audio Input | ||
|---|---|---|
| Two-way audio input: | � | 1-ch, RCA (2.0 Vp-p, 1k?) |
| IP video input: | � | 8-ch |
| Network | ||
|---|---|---|
| Incoming bandwidth: | � | 80Mbps |
| Outgoing bandwidth: | � | 160Mbps |
| Video/Audio Output | ||
|---|---|---|
| HDMI Output: | � | 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Recording Resolution: | � | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| VGA Output: | � | 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Decoding | ||
|---|---|---|
| Capability: | � | 8-ch@1080P |
| Live view / Playback: | � | 8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Hard Disk | ||
|---|---|---|
| SATA: | � | 2 SATA interfaces for 2 HDDs |
| Capacity: | � | Up to 6TB capacity for each HDD |
| External Interface | ||
|---|---|---|
| USB Interface: | � | 2, USB2.0 |
| Alarm In: | � | 4-ch |
| Alarm Out: | � | 1-ch |
| POE | ||
|---|---|---|
| Interface: | � | 8 independent 10 /100 Mbps PoE Ethernet interfaces |
| General | ||
|---|---|---|
| Power Supply: | � | 100 to 200 VAC |
| Consumption(without hard disk and POE): | � | ? 15 W |
| Working Temperature: | � | -10 oC ~ 55 oC ( 14 oF~ 131 oF) |
| Working Humidity: | � | 10 % ~ 90 % |
| Chassis: | � | 385 mm chassis |
| Dimensions: | � | 385 � 315� 52 mm (15.2" 12.4" 2.0") |
| Weight(without HDD): | � | ? 3 kg (6.6 lb) |
�INCLUDES: 2 YEAR WARRANTY�
